A2 CXT Cable Gland

Size	20 mm to 90 mm S & L
Standard	BS 6121
Application	Outdoor or Indoor for use with all types of Unarmoured Cable.
Function	A2 CXT type glands provide a single pull resistant seal on the outer sheath of unarmoured cable.
IP Rating	IP66 & 68
Optional Threads	METRIC, NPT, BSP & PG
Finish	Natural Brass Finish, Nickel Finish.
Operating Temperature	Standard seals -20° C to +80° C.
Accessories	Matching Accessories available like PVC Shrouds, Lock Nuts & Earth Tag.

Size	Thread Size 'C'		Minimum Length of Thread 'D'	Cable Range
Size	MM	INCH	Minimum Length of Thread 'D'	MAX 'A'	MAX 'B'
A2 CXT 20S	M20	½”	10	11.50	8.00
A2 CXT 20L	M20	½”	10	13.50	11.00
A2 CXT 25S	M25	3/4″	10	16.50	13.00
A2 CXT 25L	M25	3/4″	10	19.50	16.00
A2 CXT 32L	M32	1″	10	25.50	19.00
A2 CXT 40S	M40	1¼”	15	29.00	23.00
A2 CXT 40L	M40	1¼”	15	32.00	25.00
A2 CXT 50S	M50	1½”	15	37.00	31.50
A2 CXT 50L	M50	2″	15	43.00	36.50
A2 CXT 63S	M63	2″	15	50.00	42.50
A2 CXT 63L	M63	2½”	15	55.00	49.50
A2 CXT 75S	M75	2½”	15	61.00	54.50
A2 CXT 75L	M75	3″	15	67.00	60.50
A2 CXT 90	M90	3″	20	78.00	65.00
