Aluminium - Copper Bi-Metal Cable Lugs
Technical Details
Cable mm2 |
Dimensions |
|||||
A |
C |
D |
E |
J |
B |
|
16 |
5.5 |
16 |
20 |
10.3 |
79 |
43 |
25 |
6.5 |
16 |
20 |
10.3 |
79 |
43 |
35 |
8 |
16 |
20 |
10.3 |
79 |
43 |
50 |
9 |
20 |
25 |
12.8 |
85 |
43 |
70 |
11 |
20 |
25 |
12.8 |
85 |
43 |
95 |
12.5 |
20 |
25 |
12.8 |
85 |
43 |
120 |
13.7 |
25 |
30 |
12.8 |
108 |
59 |
150 |
15.5 |
25 |
30 |
12.8 |
108 |
59 |
185 |
17 |
32 |
35 |
14.5 |
115 |
59 |
240 |
19.5 |
32 |
35 |
14.5 |
115 |
59 |
300 |
23.3 |
40 |
36 |
16.5 |
137 |
85 |
400 |
26 |
40 |
36 |
16.5 |
153.5 |
85 |
500* |
29.1 |
47 |
60 X 60 |
4Ø 9 |
196 |
95 |
630* |
33.5 |
47 |
60 X x60 |
4Ø 9 |
196 |
95 |
800* |
37.5 |
53 |
80 X 80 |
4Ø 9 |
232 |
100 |
1000* |
42 |
60 |
80 X 80 |
4Ø 9 |
256 |
126 |
1300* |
46.5 |
65 |
80 X 80 |
4Ø 11 |
267 |
136 |
