Specification:

According to American standards, UL 44 & UL 1581 - (UL LISTED).

Conductor:

19 wire combination of round unilay stranded conductor provides more flexibility and optimal shape with less diameter.

Insulation:

Thermoseting XLPE insulation suitable for 90 ºC dry and 75 ºC wet location. Wires are chemical resistance and complying to flame and smoke requirment of UL 44 FT2/FH/Horizontal Flame.

Special Requirement:

UL LISTED upon request

Specification:

Appliance Wiring Material type AWM according to American Standards UL 758 & UL 1581.

Conductor:

19 wire combination of round uni-lay or semi-lay stranded conductor provides more flexibility and optimal shape with less diameter.

Insulation:

Thermoplastic PVC insulation suitable for 105 ºC. Wires are complying to Horizontal Flame test and Vertical Flame test requirements VW-1. Colors & packing options are available upon request.

Special Requirement (Upon Request):

• Available as Solid conductor.
• Copper Tinned Coating.

Specification:

Designation Type 60227 IEC 01 & BS EN 50525-2-31 and SASO 1320. Flame Retardant to IEC 60332-1 Vertical Flame Propagation Test.

Conductor:

Soft annealed copper according to BS EN 60228, Class 1, Class 2 stranded and Class 5 flexible conductor.

Insulation:

Thermoplastic insulation type PVC/E according to IEC 60227 90°C & wire heat resistant type TI - 3 to BS EN 50363-3 also 70 °C PVC type TI - 1 to BS EN 50363-3 is available. Colors are available upon request.

Special Requirement (Upon Request):

• Max. Conductor Temperature 105 °C.
• Oil and sunlight resistant.
• Different packing options are available.

Specification:

Designation Type 6231. Flame Retardant to IEC 60332-1 Vertical Flame Propagation Test.

Conductor:

Soft annealed copper according to BS EN 60228, Class 5 flexible conductor.

Insulation:

Thermoplastic insulationThe insulation PVC shall be type PVC TI 1 70 °C as specified in BS EN 50363-3 and type PVC TI 3 90 °C as specified in BS EN 50363-3. Colors are available upon request.

Special Requirement (Upon Request):

• Max. Conductor Temperature 105 °C.
• Oil and sunlight resistant.
• Different packing options are available.

Specification:

Multi-Core Flecible Cable, Designation type 60227 IEC 53, BS EN 50525-2-11 & SASO 1321 Flame Retardant to IEC 60332-1 Vertical Flame Propagation Test.

Conductor:

Annealed flexible copper as per BS EN 60228 class 5 flexible conductor.

Insulation:

Thermoplastic insulationThe insulation PVC shall be type PVC TI 1 70 °C as specified in BS EN 50363-3 and type PVC TI 3 90 °C as specified in BS EN 50363-3.

Sheathing:

White PVC color, or on request.

Specification:

According to IEC and BS standards. Flame Retardant to IEC 60332-1 Vertical Flame Propagation Test.

Conductor:

Soft annealed copper according to BS EN 60228, Class 1, Class 2 stranded and Class 5 flexible conductor.

Insulation:

Thermoplastic insulationThe insulation PVC shall be type PVC TI 1 70 °C and type PVC TI 3 90 °C.

Sheathing:

White PVC color, or on request.
