Cable Cleats
Description
- Suitable for use with cable diameters 30 to 135 mm.
- Manufactured from Aluminium alloy.
- Two -piece, two fixing design.
- Can be double stacked on common fixings.
- Operating temperature – 60°C to +105°C.
- Suitable for LV & HV cables upto 132KV.
- Can be used for all types of cable routes.
- Plain finish for normal industrial areas or indoor application.
- Epoxy coated version available for harsh environments/outdoor.
- Optional Neoprene & EPDM liner available.
- In accordance with BS EN 61914:2009.
- Short circuit withstand : 110 KA (peak).
- Supplied with SS 304 Fasteners.
Technical Details
Cable Diameter (mm) |
Cable Diameter With Liner (mm) |
W(mm) |
H(mm) |
D(mm) |
P(mm) |
Fixing Bolt |
|||
Min |
Max |
Min |
Liner Thk. |
Max |
|||||
|---|---|---|---|---|---|---|---|---|---|
30 |
40 |
24 |
3 |
34 |
93 |
42 |
45 |
71 |
2 X M10 |
40 |
50 |
34 |
3 |
44 |
104 |
52 |
45 |
82 |
2 X M10 |
48 |
55 |
42 |
3 |
49 |
108 |
60 |
45 |
86 |
2 X M10 |
55 |
64 |
49 |
3 |
58 |
118 |
67 |
50 |
95 |
2 X M10 |
64 |
70 |
58 |
3 |
64 |
125 |
76 |
50 |
102 |
2 X M10 |
70 |
76 |
64 |
3 |
70 |
130 |
82 |
50 |
108 |
2 X M10 |
76 |
83 |
70 |
3 |
77 |
138 |
90 |
60 |
115 |
2 X M12 |
83 |
89 |
77 |
3 |
83 |
144 |
97 |
60 |
121 |
2 X M12 |
89 |
95 |
83 |
3 |
89 |
152 |
107 |
60 |
130 |
2 X M12 |
95 |
101 |
85 |
5 |
91 |
158 |
113 |
60 |
136 |
2 X M12 |
101 |
115 |
91 |
5 |
105 |
175 |
119 |
85 |
152 |
2 X M12 |
115 |
125 |
105 |
5 |
115 |
180 |
133 |
85 |
158 |
2 X M12 |
125 |
135 |
115 |
5 |
125 |
192 |
143 |
85 |
170 |
2 X M12 |
