Copper One Hole Offset Tongue Cable Lugs / Terminals
Technical Details
Copper Wire Range (AWG) |
Screw Size |
Screw Type |
Dimensions in mm |
|||||
F |
E |
D |
G |
H |
T |
|||
#14 - #10 |
48 A |
SCREW-1 |
26 |
12 |
7 |
5.3 |
7.95 |
9.5 |
#14 - #6 |
1/4" UNF |
SCREW-2 |
31.5 |
15 |
11 |
5.6 |
10 |
12.3 |
#8 - #2 |
5/16" UNF |
SCREW-2 |
39.5 |
20.5 |
12.7 |
6.35 |
12 |
16.3 |
#6 - #1/0 |
3/8" UNF |
SCREW-2 |
50.18 |
26.16 |
15.35 |
10.63 |
15.93 |
23.05 |
#4 - #3/0 |
3/8" UNF |
SCREW-3 |
55.67 |
29.85 |
18.17 |
10.87 |
19.17 |
26.36 |
#2 - #4/0 |
7/16" UNF |
SCREW-3 |
64.86 |
33.57 |
23.94 |
12.78 |
25.25 |
29.68 |
#1/0 - 350 |
5/8" UNF |
SCREW-3 |
71.68 |
33.55 |
30.85 |
12.97 |
25.25 |
35.65 |
#1/0 - 500 |
5/8" UNF |
SCREW-3 |
103.78 |
56.28 |
36.15 |
22.95 |
38.05 |
40.75 |
600 - 1000 |
3/4" UNF |
SCREW-3 |
122.75 |
60.87 |
47.15 |
28.37 |
49.86 |
59.05 |
