Specification:

Electrical low voltage cables complying with IEC 60502-1 BS 7846. Our products tested at internationally reputable labs,LPCB, BASEC & bsi. All cable are Flame Retardant to IEC 60332-3.24 Category C Flame Propagation Test, Oil esistance and Sunlight & UV Resistant. Fire resistant test as per BS 6387 (CWZ) 950 °C for 3 hour.

Conductor

High conductivity soft annealed copper according to BS EN 60228, Class 1, Class 2 stranded and Class 5 flexible conductor wrapped with mica tapes. Conductor can be offered with round, round compacted and sectored shape.

Insulation

Cross-linked polyethylene (XLPE) with Maximum service temperature 90ºC..

Armoring (upon request):

• Aluminum Wire Armored “AWA” for single core cable.
• Galvanized steel wire “SWA” for multi core cable.

Outer Sheathing

Low Smoke & Fume Zero Halogen (LS0H).

Special Requirements (upon request):

• High flame propagation tests: IEC 60332-3.23 Category B - IEC 60332-3.22 Category A
• Fire performance: F120 - F2 - IEC 60331 - BS 6387 (CWZ)
• Water resistance
• Anti-termite resistant
• Shield type
• Polyvinyl chloride (PVC ST2) outer sheath
• Special color for insulation and outer sheath
• Different packing options are available
