Standards:

UL 13/UL 2250, TYPE PLTC/ITC.

Conductor:

Stranded Plain Copper or Tinned Copper, as per ASTM B3/B33.

Insulation:

XLPE, Cross-linked Polyethylene compound.

Cores Identification:

• As Pairs: Black and White, numbered for multipair.
• As Triads: Black, White and Red, numbered for multi-triad.

Cores Assembly:

• Individual Pair/Triad Assembly: Insulated cores are twisted into a pair/triad.
• Overall Assembly: Twisted pairs/triads assembled in layers followed by polymer binder tape.

Shielding:

• Individual Pair/Triad Shield: Aluminum foil/polyester shield wrapped to provide 100% coverage with a tinned copper drain wire that is minimum one even gauge size smaller than conductor size.
• Overall Shield: Aluminum foil/polyester shield wrapped to provide 100% coverage with a tinned copper drain wire that is minimum one even gauge size smaller than conductor size.

Outer Sheathing:

Black PVC, Heat Resistant Polyvinylchloride Flame Retardant

Special Requirement (upon request):

• Alternate color / identification for cores
• Alternate outer sheath colors
• Lead sheathed
• Fire Resistant
• Eco-Friendly, Low Smoke & Zero Halogen (LS0H) Sheathed

Standards:

• FF-844 Type A, H1 Cable.
• IEC 61158-2 Section 12.8.2.
• UL 13/UL 2250, TYPE PLTC/ITC.

Conductor:

Stranded Tinned Copper, as per ASTM B33.

Insulation:

XLPE, Cross-linked Polyethylene compound.

Cores Identification:

As Pairs: Black and White, numbered for multipair.

Cores Assembly:

• Individual Pair Assembly: Insulated cores are twisted into a pair.
• Overall Assembly: Twisted pairs assembled in layers followed by polymer binder tape.

Shielding:

• Individual Pair/Triad Shield: Aluminum foil/polyester shield wrapped to provide 100% coverage with a tinned copper drain wire that is minimum one even gauge size smaller than conductor size.
• Overall Shield: Aluminum foil/polyester shield wrapped to provide 100% coverage with a tinned copper drain wire that is minimum one even gauge size smaller than conductor size.

Armoring (upon request):

Round Galvanized Steel wires

Outer Sheathing:

Orange PVC, Heat Resistant Polyvinylchloride Flame Retardant

Special Requirement (upon request):

• Alternate color / identification for cores
• Alternate outer sheath colors
