Specification:

Electrical low voltage cables complying with IEC 60502-1 BS 5467. Our products tested at internationally reputable labs, KEMA. All cable are Flame Retardant to IEC 60332-1 Vertical Flame Propagation Test.

Conductor:

High conductivity soft annealed copper according to BS EN 60228, Class 1, Class 2 stranded and Class 5 flexible conductor and Stranded aluminum conductor Class2. Conductor can be offered with round, round compacted and sectored shape.

Insulation:

Polyvinyl chloride (PVC) & Cross-linked polyethylene (XLPE) with Maximum service temperature 90ºC.

Armoring (upon request):

• Aluminum Wire Armored “AWA” or Aluminum Tape Armored ATA for single core cable.
• Galvanized steel wire “SWA” or galvanized double steel tape “STA"for multi core cable.

Outer Sheathing:

Polyvinyl Chloride (PVC ST2).

Special Requirement (upon request):

• High fire performance, Flame propagation tests: IEC 60332-3
• Sunlight & UV Resistant
• Water resistance
• Anti-termite resistant
• Lead sheath
• Shield type
• Special color for insulation and outer sheath
• Special outer sheath material: PVC(FRLS), LLDPE, LDPE,MDPE and HDPE
• Different packing options are available
