LSF0H Wires & Cables
Cu/LSOH-XL | 450/750V | BS Standard
Specification:
Designation Type H07Z-U, H07Z-R and H07Z-K BS EN 50525-3-41 (Formerly BS 7211:1998). Flame Retardant to IEC 60332-1 Vertical Flame Propagation Test. Our products tested at internationally reputable labs, BASEC & bsi.
Conductor:
Soft annealed copper according to BS EN 60228, Class 1, Class 2 stranded and Class 5 flexible conductor.
Insulation:
Halogen free, low smoke cross-linked material (LS0H-XL) of Type EI 5 to EN 50363-5 90 °C. Colors are available upon request.
Special Requirement (upon request):
- Different packing options are available.
XLPE insulated LS0H sheathed cables 0.6/1.0 kV and 1.8/3.0 kV, IEC & BS Standards
Specification:
Electrical low voltage cables complying with IEC 60502-1 BS 6724. Our products tested at internationally reputable labs, BASEC & bsi. All cable are Flame Retardant to IEC 60332-3.24 Category C Flame Propagation Test, Oil resistance and Sunlight & UV Resistant.
Conductor
High conductivity soft annealed copper according to BS EN 60228, Class 1, Class 2 stranded and Class 5 flexible conductor and Stranded aluminum conductor Class2. Conductor can be offered with round, round compacted and sectored shape.
Insulation
Cross-linked polyethylene (XLPE) with Maximum service temperature 90ºC.
Armoring (upon request):
- Aluminum Wire Armored “AWA” for single core cable.
- Galvanized steel wire “SWA” for multi core cable.
Outer Sheathing
Low Smoke & Fume Zero Halogen (LS0H).
Special Requirements (upon request):
- High fire performance, Flame propagation tests: IEC 60332-3.23 Category B - IEC 60332-3.22 Category A
- Water resistance
- Anti-termite resistant
- Shield type
- Special color for insulation and outer sheath
- Different packing options are available
