Mechanical Cable Lugs
Technical Details
Cable mm2 |
Dimensions |
|||||
A |
G |
D |
J |
Screw |
Type |
|
10 |
4 |
6 |
15 |
32.5 |
M - 5 |
I |
16 |
5.1 |
8.5 |
17 |
37 |
M - 5 |
I |
25 |
6.3 |
8.5 |
18.75 |
42 |
M - 5 |
I |
35 |
7.5 |
10.5 |
21.5 |
4 |
M - 5 |
I |
50 |
9.5 |
10.5 |
23 |
56.5 |
M - 6 |
II |
75 |
11 |
13.25 |
26 |
61 |
M - 6 |
II |
100 |
13 |
14.3 |
29 |
65 |
M - 6 |
II |
120 |
14 |
14.8 |
32 |
71 |
M - 6 |
II |
170 |
16 |
16 |
33 |
81 |
M - 8 |
II |
200 |
17 |
17 |
35 |
85 |
M - 8 |
II |
250 |
18 |
17 |
38 |
87.5 |
M - 8 |
II |
300 |
21 |
19.8 |
45 |
118 |
M - 10 |
II |
400 / 500 |
25.5 |
22 |
53 |
132 |
M - 10 |
II |
700 |
34 |
22 |
60 |
150 |
M - 10 |
II |
