Overhead Transmission Lines
Aerial Bundle Cables (ABC)
Description
Service drop cables are composed of one or more concentric-lay-stranded Aluminum 1350 phase conductors insulated with an extruded layer of cross-linked polyethylene compound and assembled with one neutral conductor of All Aluminum Conductors (AAC); Aluminum-Alloy Conductors 6201-T81 (AAAC); Aluminum Conductors, Steel-Reinforced (ACSR); or Aluminum Conductors, Aluminum-Clad Steel Reinforced (ACSR/AW).
The neutral conductor may be bare or covered with an extruded layer of cross-linked polyethylene compound.
Applications
The use of these service drop or secondary distribution cables is limited to circuits, not exceeding 600 volts phase-to-phaseor 480 volts phase-to-ground, to a normal temperature rating of the service conductor temperature of 90 °C.
Standards
- IEC 60502, IEC 60228, IEC 61089, BS EN 50182
- ASTM B549, ASTM B232
- ANSI / ICEA S-76-474
Instrumentation Cable UL 1277 Type TC, 600V
Description
Non-insulated Bare Conductors of Copper, Aluminum or composite of Aluminum and steel/steel clad materials.
Types
- BARE HARD DRAWN CONDUCTOR COPPER (BHDC)
- ALL ALUMINUM CONDUCTORS (AAC)
- ALL ALUMINUM ALLOY CONDUCTORS (AAAC)
- ALUMINUM CONDUCTOR STEEL REINFORCED (ACSR)
- ALUMINUM CONDUCTOR, ALUMINUM CLAD STEEL REINFORCED (ACSR/AW)
- ALUMINUM CONDUCTOR, ALUMINUM ALLOY REINFORCED (ACAR)
Standards
- IEC 61089, BS EN 50182, BS EN 50183, BS EN 50189
- ASTM B231, ASTM B399, ASTM B232, ASTM B549
- DIN 48201, BS 215
