Description

Split bolt connectors are a type of electrical connector used to connect two or more wires together. It is called a “split bolt” connector because it consists of a bolt with a split in the middle, allowing the connector to be opened and the wires to be inserted. The bolt is then tightened to secure the wires in place. These connectors are commonly used in applications where a secure, reliable connection between multiple wires is needed. They are often used in place of other types of connectors, such as crimp connectors, because they are considered to be stronger and more reliable. They are also easy to install, making them a popular choice among electrical and electronic professionals.

Split bolt connectors are commonly used in grounding applications, such as in lightning protection systems and electrical grounding systems. In these systems, the connectors are used to join the grounding wires and other components together, creating a complete circuit that provides a path for electricity to flow to the ground. The use of these connectors in grounding applications allows for a secure, reliable connection that can withstand the high currents and voltages associated with electrical grounding and lightning protection

Technical Details

Material :	» Extruded / Forged Brass Section BS2874
Finish :	» Electro-Tinned / Untinned or Copper Plated.

Cable Size mm2	Dimensions in mm (A)
10	4.5
16	6
25	6.9
32-35	8.1
50	9.7
70	11.2
95	13.6
100	14
120	15
150	16.6
185	18.2
240	21.4
300	23.7
400	26.2
500	30.1
