Cables Ties
Ball Lock Type Cable Ties
Designed with Wedge Lock Mechanism System, it is offered with Epoxy/Pure Polyester coating. Multi-colored cable ties are available upon request. Ball Lock Cable Ties are designed with Wedge Lock Mechanism System for quick installation with low insertion force. They are resistant to corrosion and suitable for indoor, outdoor or harsh environments.
| Type : | » Ball Lock Type (Roller Ball Un-coated and Coated) |
| Standard Size : | » 4.6 mm & 7.9 mm Width |
| Optional Size : | » 12 mm & 16 mm Width |
| Operating Temprature: | » Approx : -80°C to +538°C (Un-coated) and -80°C to + 150°C (Coated) |
| Standard Material : | » SS316 and SS304 |
| Min Loop Tensile Strength : | » 130 lbs for 4.6mm width Un-coated » 270 lbs for 7.9mm width Un-coated. » 110 lbs for 4.6mm width Coated » 00 lbs for 7.9mm width Coated |
Ladder Type Cable Ties
Ladder Type Cable ties with Pure Polyester coating, using ratchet mechanism. Ladder Type Cable Ties are designed with Ratchet Mechanism System. They are resistant to corrosion and suitable for indoor, outdoor or harsh environments.
| Type : | » Ladder Type (Un-coated and Coated) |
| Standard Size : | » 7 mm & 12 mm Width |
| Operating Temprature: | » Approx : – -80°C to +538°C (Un-coated) and -80°C to +150°C (Coated) |
| Standard Material : | » SS316 and SS304 |
| Min Loop Tensile Strength : | » 100 lbs for 7mm width » 200 lbs for 12mm width |
Releasable Type Cable Ties
Releasable type cable ties with special grade polymer coating with PPA-517 material for superior hygroscopic and corrosion resistance properties, they are reusable and convenient for temporary installation and cable pulling. Releasable Cable Ties are used for multiple installation over long period of time. They are made with special grade polymer coating for superior hygroscopic and corrosion resistance properties and suitable for indoor, outdoor or harsh environments.
| Type : | » Releasable Type (Un-coated and Coated) |
| Standard Size : | » 6.3 mm & 9.5 mm Width |
| Operating Temprature: | » Approx : -40°C to +325°C (Un-coated) and -60°C to + -170°C (Coated) |
| Standard Material : | » SS316 and SS304 |
| Min Loop Tensile Strength : | » 400 lbs for 6.3mm width (Un-coated & Coated) » 500 lbs for 9.5mm width (Un-coated & Coated) |
