A2 Series A2F Cable Gland
Description
DNG Exports’ CABLE GLAND A2 Series’, Type: A1-A2 The A2 Series* single compression cable glands maintain Flameproof Exd and Increased Safety Exe methods of explosion protection IP67. Type Al-A2 is intended for all types unarmoured and braid armoured cable. The A2 Series* cable gland type A1-A2 consists of Lock Nut, Thread Seals, Gland Body, Sealing Ring, Nylon Washer and Bush. For use with Electrical apparatus in Zone 1, 2, 21, 22 areas. Groups IIA, 11B, IIC,IIIC.
Technical Details
| Design Standard | EN EN 60079-1:2014, EN 60079-31:2014, BS6121, EN62444:2013, IEC 60529 |
|---|---|
| Ingress Protection | IP 67 |
| Material | Brass: 2874 CZ121 /IS 319 gr.l Stainless Steel : ASTM A314 gr. 304/316 L Mild Steel |
| Threads | ISO Metric National pipe Thread (NPT) British Standard pipe (BSP) Imperial (ET) |
| Seals | T117ATEX 822 X- Ex Notified Body No. 1354 |
| Plating | Brass Finish / Nickel Finish / Chrome Finish |
| Operating Temperature | The Standard cable sealing washer (EPDM Elastomeric sealing ring) used and is suitable for operating temperature – 60t Tamb +1250C |
| Accessories | Lock Nut, Earth Tag, IP Nylon Washer, Serrated Washer, PVC / LSF Shroud |
