Technical Details

Size 20 mm to 90 mm S & L
Standard BS 6121
Application For indoor or outdoor use with all types of SWA Cable.
Function CW type glands provide a seal on the outer sheath and an armour specific armour clamp for armoured cable. The armour clamp provides an electrical bond armour cable and the gland..
IP Rating IP66
Optional Threads METRIC, NPT, BSP & PG
Finish Natural Brass Finish, Nickel Finish.
Operating Temperature Standard seals -20° C to +80° C.
Accessories Matching Accessories available like PVC Shrouds, Lock Nuts, Earth Tags, Reducers, Adaptors, etc.

Specification

Size
Thread Size 'C'
Minimum Length of
Thread 'D'
Cable Range
MM
INCH
MAX 'A'
MAX 'B'
CW 20S M20 ½” 10 11.50 15.50
CW 20L M20 ½” 10 14.00 20.50
CW 25S M25 3/4″ 10 18.00 24.00
CW 25L M25 3/4″ 10 20.00 27.20
CW 32S M32 1″ 10 26.30 33.50
CW 32L M32 1″ 15 26.30 33.50
CW 40S M40 1¼” 15 31.50 39.50
CW 40L M40 1¼” 20 32.00 40.00
CW 50S M50 1½” 20 38.20 46.30
CW 50L M50 2″ 20 44.00 52.60
CW 63S M63 2″ 20 50.10 59.00
CW 63L M63 2½” 20 56.00 65.30
CW 75S M75 2½” 20 62.00 71.60
CW 75L M75 3″ 20 68.00 78.00
CW 90S M90 3″ 20 80.50 91.00
CW 90L M90 3″ 20 80.50 91.00
